V2406/2422/2426 Hardware Manual Hardware Introduction
2-6
ATTENTION
There is a risk of explosion if the wrong type of battery is used. To avoid this potential danger, always be sure
to use the correct type of battery.
Dispose of used batteries according to the instructions on the battery.
Contact the Moxa RMA service team
if you need to replace your battery.
