EXPC-1319 Series Hardware Hardware Installation
2-12
3. Carefully insert the CompactFlash card into the socket, hardware
interface first (shown at right). To remove the card, you may need to
use a screwdriver or other long, slender tool.
4. When finished, place the cover back and fasten the screws.
NOTE
Please note that the SSD/CompactFlash cover comes with rubber pads
fastened to the back plate, to help secure the SSD and CF cards. These
pads also help reduce vibration and assist in keeping the SSD and CF
slots waterproof, so take care to preserve them and follow suggested
procedures when securing the cover.
