USB Hosts

The MC-4510-C23 has six USB 2.0 full speed hosts that use a type A

connector. The port supports keyboard and mouse, and can also be used

to connect a FlashDisk for storing large amounts of data.

Audio Interface

The MC-4510-C23 comes with an audio input and an audio output,

allowing users to connect a speaker or an earphone.

Reset Button

Press the “Reset Button” on the front panel of the MC-4510-C23, and the

system will reboot automatically. The Ready LED will blink on and off

for the first 5 seconds, and then maintain a steady glow once the system

has rebooted.

Real-time Clock

The MC-4510-C23's real-time clock is powered by a lithium battery. We

strongly recommend that you do not replace the lithium battery without

help from a qualified Moxa support engineer. If you need to change the

battery, contact the Moxa RMA service team.

ATTENTION

There is a risk of explosion if the battery is replaced with an incorrect

type of battery.

6. Powering on the MC-4510-C23

To power on the MC-4510-C23, connect the “terminal block to power

jack converter” to the MC-4510-C23's DC terminal block (located on the

side panel), and then connect the power adaptor. Press the Power Switch

button to turn on the computer. Note that the Earth Ground wire should

be connected to the top pin of the terminal block. It takes about 30

seconds for the system to boot up. Once the system is ready, the Power

LED will light up.
