MC-4510-C23 HW User’s Manual Introduction
1-4
Operating
Humidity
5 to 95% RH
Storage
Temperature
-20 to 60°C (-4 to 140°F)
Anti-vibration
0.7 @ DNV 2.4 (Class A), sine wave, 2-100 Hz, 1 Oct./min., 1.5 hr
per axis
1 grms @ DNV 2.4, random wave, 3-100 Hz, 2.5 hr per axis
2.1 g @ DNV 2.4 (Class C), sine wave, 2-50 Hz, 1 Oct./min., 1.5 hr
per axis
Anti-shock
50 g @ IEC 60068-2-27, half sine wave, 11 ms
Power Requirements
Input Voltage
18 to 36 VDC (3-pin terminal block)
Power
Consumption
48.6 W
1.35 A @ 36 VDC
1.96 A @ 24 VDC
2.61 A @ 18 VDC
Regulatory Approvals
EMC
CE (EN55022 Class B, EN55024-4-2, EN55024-4-3, EN55024-4-4),
FCC (Part 15 Subpart B, Class B)
Safety
UL/cUL (UL60950-1, DVN, IEC 60954 (4th), IACS0-E10
Reliability
Alert Tools
Built-in buzzer and RTC (real-time clock)
Automatic Reboot
Trigger
Built-in WDT (watchdog timer)
Warranty
Warranty
3 years
Details
See www.moxa.com/warranty
