Moxa MC-4510-C23 [6/44] Mc 4510 c23 hardware specifications
![Moxa MC-4510-C23 [6/44] Mc 4510 c23 hardware specifications](/views2/1200667/page6/bg6.png)
MC-4510-C23 HW User’s Manual Introduction
1-3
MC-4510-C23 Hardware Specifications
Computer
CPU
Intel Core 2 Duo SP9300 2.26 GHz, 6 MB for L2 cache
OS
Windows 7, Windows XP SP3, Windows XP Embedded (Must be
installed by the user)
System Chipset
Intel GS45 + ICH9M
DRAM
2 GB DDR3 SDRAM onboard (supports DDR3 up to 4 GB)
USB
USB 2.0 host x 6
Expansion Bus
Mini-PCIe onboard
Storage
Storage Expansion
CompactFlash socket
HDD Support
2 SATA connectors for HDD expansion
Other Peripherals
Audio
Line-in/out interface
Display
Graphics
Controller
Intel GS45
VGA Interface
15-pin D-Sub connector x 1(female)
DVI-D Interface
25-pin DVI-D connector x 1 (female)
Ethernet Interface
LAN
2 auto-sensing 10/100/1000 Mbps ports (RJ45)
Magnetic Isolation
Protection
1.5 KV built-in
Serial Interface
Serial Standards
2 RS-232/422/485 ports, software-selectable (DB9 Male)
Optical Protection
2 KV
Serial Communication Parameters
Data Bits
5, 6, 7, 8
Stop Bits
1, 1.5, 2
Parity
None, Even, Odd, Space, Mark
Flow Control
RTS/CTS, XON/XOFF, ADDC® (automatic data direction control) for
RS-485
Baudrate
50 bps to 921.6 Kbps (supports non-standard baudrates; see user's
manual for details)
Serial Signals
RS-232
TxD, RxD, DTR, DSR, RTS, CTS, DCD, GND
RS-422
TxD+, TxD-, RxD+, RxD-, GND
RS-485-4w
TxD+, TxD-, RxD+, RxD-, GND
RS-485-2w
Data+, Data-, GND
LEDs
System
System: Storage, Power
LAN
LAN: 10M/Link x 2, 100M/Link x 2 (on connector)
Physical Characteristics
Housing
Aluminum, sheet metal
Weight
3.75 kg
Dimensions
302 x 70 x 279 mm (11.98 x 2.76 x 10.98 in)
Mounting
wall
Environmental Limits
Operating
Temperature
-10 to 55°C (14 to 131°F)
