Moxa MPC-122Y-K [3/3] Ordering information

Moxa MPC-122X-K [3/3] Ordering information

Marine Displays and Computers

Other Peripherals

KB/MS: 1 PS/2 interface supporting standard PS/2 keyboard and

mouse through Y-cable

Audio: line in, line out; 3.5 mm mini-jack

Display

Panel Size: 22’’ viewable image size

Panel Type: MVA

Aspect Ratio: 16:10

Pixels: 1680 x 1050 (WSXGA+)

Pixel Pitch (RGB): 0.282 (H) x 0.282 (V) mm

Response Time: 8 ms (gray to gray)

Contrast Ratio: 1000:1

Light Intensity: 300 cd/m

Viewing Angles: 178˚/178˚

Active Display Area: 473.76 (H) x 296.1 (V) mm

Max Colors: 16.7M / 8-bit color

Resolution:

• VGA: 640 x 480

• SVGA: 800 x 600

• XGA: 1024 x 768

• SXGA: 1280 x 1024

• WSXGA+: 1680 x 1050 (optimal setting)

Ethernet Interface

LAN: 2 auto-sensing 10/100/1000 Mbps ports (RJ45)

Magnetic Isolation Protection: 1.5 kV built-in

Serial Interface

Serial Standards: 2 software-selectable RS-232/422/485 ports, male

DB9

Optical Isolation Protection: 4 kV

Serial Communication Parameters

Data Bits: 5, 6, 7, 8

Stop Bits: 1, 1.5, 2

Parity: None, Even, Odd, Space, Mark

Flow Control: RTS/CTS, XON/XOFF, ADDC® (automatic data direction

control) for RS-485

Baudrate: 50 bps to 921.6 kbps (supports non-standard baudrates;

see user’s manual for details)

Serial Signals

RS-232: TxD, RxD, DTR, DSR, RTS, CTS, DCD, GND

RS-422: TxD+, TxD-, RxD+, RxD-, GND

RS-485-4w: TxD+, TxD-, RxD+, RxD-, GND

RS-485-2w: Data+, Data-, GND

LEDs

System: Storage, Power

LAN: 100M/Link x 2, 1000M/Link x 2 (on connector)

Front Panel

LEDs: Storage, Power

OSD: 5 display control buttons

USB: 1 USB 2.0 port

Potentiometer: For brightness control

Physical Characteristics

Housing: Aluminum sheet metal

Weight: 15 kg

Dimensions: 124 x 560 x 420 mm (4.88 x 22.05 x 16.54 in)

Mounting: Flush mounting

Environmental Limits

Operating Temperature: -15 to 55°C (5 to 131°F)

Storage Temperature: -20 to 60°C (-4 to 140°F)

Ambient Relative Humidity: 5 to 95% (non-condensing)

Anti-Vibration:

• IEC 60945

• DNV 2.4, Class A/Class C

Power Requirements

Input Voltage: 24 VDC (18 to 36 VDC), screw-type terminal block

Power Consumption: 112 W

• 6.21 A @ 18 VDC

• 4.55 A @ 24 VDC

• 2.95 A @ 36 VDC

Standards and Certifications

Safety: UL/cUL, CCC

EMC: EN 55022 Class B, EN 55024-4-2, EN 55024-4-3, EN 55024-4-4,

FCC Part 15 Subpart B Class A

Marine: IEC 60945 4th, DNV, IACS-E10

Green Product: RoHS, cRoHS, WEEE

Reliability

Automatic Reboot Trigger: Built-in WDT (watchdog timer) supporting

1-255 levels for time interval system reset, software programmable

MTBF (mean time between failures): 39,675 hrs

Warranty

Warranty Period: 1 year

Details: See www.moxa.com/warranty

Ordering Information

Available Models

MPC-122X-K: Intel Core 2 Duo 2.26 GHz panel computer with 22” screen, full-dimming, tape

bonding

MPC-122Y-K: Intel Core 2 Duo 2.26 GHz panel computer with 22” screen, full-dimming, optical

bonding

MPC-122X-K-ECDIS: Intel Core 2 Duo 2.26 GHz panel computer with 22” screen, full-dimming, tape

bonding, ECDIS

MPC-122Y-K-ECDIS: Intel Core 2 Duo 2.26 GHz panel computer with 22” screen, full-dimming,

optical bonding, ECDIS

Package Checklist

• MPC-122-K panel computer

• PS/2 to KB/MS Y-cable

• 2 hard drive cables and 1 SATA disk

power cable

• Rubber waterproofing gasket

• Documentation and software CD

• Quick installation guide (printed)

• Warranty card

We recommend taking the following precautions to minimize heat

build-up within the display:

• Position the display within ±40° of the vertical.

• Install an external fan to increase airﬂow upwards through the

display if (a) the display is not positioned within ±40° of the

vertical, (b) the ambient temperature exceeds 25°C, or (c) the

display is used in a location with minimal ventilation.

Important Safety Precaution:

Even though the display is rated to operate within the IEC 60945

standard of -15 to 55°C, it is best to ensure that the ambient

temperature does not exceed 25°C. Doing so will increase the life

of your display and minimize service costs.
