W315A/325A Linux User's Manual Getting Started
2-4
1. Follow the instructions given in a previous section to access the Console Utility of the target computer
through the serial console port, and then type
#cd /etc/network to change directories.
2. Type
#vi interfaces to use vi editor to edit the network configuration file. You can configure the
Ethernet ports of the W315A/325A for dynamic (DHCP) IP addresses.
3. After the boot settings of the LAN interface have been modified, issue the following command to activate
the LAN settings immediately:
#/etc/init.d/networking restart
NOTE After changing the IP settings, use the networking restart command to activate the new IP address.
Modifying Network Settings over the Network
IP settings can be activated over the network, but the new settings will not be saved to the flash ROM without
modifying the file /etc/network/interfaces.
For example, type the command #ifconfig eth0 192.168.27.125 to change the LAN IP address to
192.168.27.125.
root@Moxa:~# ifconfig eth0 192.168.27.125
root@Moxa:~# _
GPRS Networks
The W315A/325A embedded computers include a GSM/GPRS module for wireless communication. The module
can be used to transmit data over a GPRS network.
Setting Up the Wireless Module
Before using the W315A/325A, make sure the SIM card is properly installed and the antenna is connected
(refer to the W315A/325A Hardware User’s Manual for details). Note that the SIM card must be installed when
the embedded computer is powered off.
The LED indicators on the front panel can be used to check the signal strength. A process running in the
background, called “egprsagent,” is responsible for this task.
Configuring the SIM Card
NOTE: Make sure you have the correct PIN code. After three failed attempts to enter the PIN code,
the SIM card will be locked, and you will need to use the PUK code to unlock the SIM card. After ten
failed attempts to enter the PUK code, the SIM card will be deactivated and will no longer be
operable.
