W315A/325A Linux User's Manual Managing Communications

4-19

NOTE Click on the following links for more information about NFS:

http://www.tldp.org/HOWTO/NFS-HOWTO/index.html

http://nfs.sourceforge.net/nfs-howto/client.html

http://nfs.sourceforge.net/nfs-howto/server.html

Setting up the W315A/325A as an NFS Client

The following procedure is used to mount a remote NFS Server.

1. To know the NFS Server’s shared directory.

2. Establish a mount point on the NFS Client site.

3. Mount the remote directory to a local directory.

#mkdir –p /home/nfs/public

#mount –t nfs NFS_Server(IP):/directory /mount/point

Example:

#mount –t nfs 192.168.3.100:/home/public /home/nfs/public

Mail

smtpclient is a minimal SMTP client that takes an email message body and passes it on to an SMTP server. It

is suitable for applications that use email to send alert messages or important logs to a specific user.

NOTE Click on the following link for more information about smtpclient:

http://www.engelschall.com/sw/smtpclient/

To send an email message, use the ‘smtpclient’ utility, which uses SMTP protocol. Type

#smtpclient –help

to see the help message.

Example:

smtpclient –s test –f sender@company.com –S IP_address receiver@company.com

< mail-body-message

-s: The mail subject.

-f: Sender’s mail address

-S: SMTP server IP address

The last mail address receiver@company.com is the receiver’s e-mail address.

mail-body-message is the mail content. The last line of the body of the message should contain ONLY the

period ‘.’ character.

You will need to add your hostname to the file /etc/hosts.

SNMP

This embedded computer supports the Net-Snmp daemon. It has not been included in the default package, but

can install by yourself when you need it. It will use about 3 MB of your embedded flash ROM. The W315A/325A

embedded computers come with SNMP V1 (Simple Network Management Protocol) agent software built in. The

software supports RFC1317 RS-232 like groups and RFC 1213 MIB-II. To install SNMP, follow these steps.

Step 1: Make sure you have enough free space

192.168.3.127 – PuTTY

root@Moxa:/bin# df -h

Filesystem Size Used Available Use% Mounted on

/dev/mtdblock2 8.0M 6.0M 2.0M 75% /
