www.moxa.com
info@moxa.com
Ethernet Media Converters
TRC-190 Series
Rackmount chassis for the NRack System™
The TRC-190 series provides 19 slots for media converter modules
from the CSM-200 series of Ethernet-to-fiber modules and the TCF-
142-RM series of serial-to-fiber modules. A TRC-190 chassis comes
with one AC or DC power input, with an optional redundant power
expansion module available for greater reliability. The TRC-190 series’
power input module supports the hot-swap feature.
Introduction
Specifications
› 19-inch chassis for rack-mount use
› 19 slots for high density applications
› Supports hot-swap and dual power input with redundancy
› Fanless chassis design reduces servicing costs
Physical Characteristics
Housing: SECC (1.2 mm)
Dimensions: 440 x 260 x 77 mm (18.6 x 11 x 3.3 in)
Weight: 5.2 kg (11.4 lbs), with one power module installed
Number of Slots: 19 slots in the front for slide-in modules, 2 slots in
the back for power supply modules
Environmental Limits
Operating Temperature: 0 to 60°C (32 to 140°F)
Storage Temperature: -20 to 75°C (-4 to 167°F)
Ambient Relative Humidity: 5 to 95% (non-condensing)
Power Requirements
Input Voltage: Universal 100 to 240 VAC (47 to 63 Hz) or 36 to 72
VDC
Power Consumption:
Max. Output: 3.2A @ 36VDC
Standards and Certifications
Safety: UL 60950-1, EN 60950-1
EMC: CE, FCC
EMI: EN 55022 Class A, FCC Part 15 Subpart B Class A
EMS:
EN 61000-4-2 (ESD) Level 3,
EN 61000-4-3 (RS) Level 2,
EN 61000-4-4 (EFT) Level 2,
EN 61000-4-5 (Surge) Level 2,
EN 61000-4-6 (CS) Level 2,
EN 61000-4-8 (PFMF) Level 3,
EN 61000-4-11 (DIPS)
Green Product: RoHS, CRoHS, WEEE
MTBF (mean time between failures)
Time: 1,055,112 hrs
Database: Telcordia (Bellcore), GB
Warranty
Warranty Period: 5 years
Details: See www.moxa.com/warranty
