Moxa TRC-190-DC [2/2] Ordering information

Ethernet Media Converters

484 (19.06)

33 (1.30)

260 (10.24) 33

440 (17.32)

88 (3.46)

TRC-190-ACx1TRC-190-DCx1TRC-190-DCx2TRC-190-ACx2

465.6 (18.33)

2.5 (0.10)

76.7 (3.02)

Ordering Information

Available Models

TRC-190-AC: Rack chassis, 2U, single 110 to 240 VAC input, with 19 slots on front panel

TRC-190-DC-48: Rack chassis, 2U, single 36 to 72 VDC input, with 19 slots on front panel

Available Slide-in Modules

CSM-200-1213: 10/100BaseT(X) to 100BaseFX slide-in module media converter, multi-mode ST connector

CSM-200-1214: 10/100BaseT(X) to 100BaseFX slide-in module media converter, multi-mode SC connector

CSM-200-1218: 10/100BaseT(X) to 100BaseFX slide-in module media converter, single-mode SC connector

TCF-142-M-SC-RM: RS-232/422/485 to multi-mode ﬁber slide-in module converter, SC connector

TCF-142-M-ST-RM: RS-232/422/485 to multi-mode ﬁber slide-in module converter, ST connector

TCF-142-S-SC-RM: RS-232/422/485 to single-mode ﬁber slide-in module converter, SC connector

TCF-142-S-ST-RM: RS-232/422/485 to single-mode ﬁber slide-in module converter, ST connector

Optional Accessories (can be purchased separately)

PWR-190-AC: Redundant power supply, 110 to 240 VAC

PWR-190-DC-48: Redundant power supply, 36 to 72 VDC

Plate-1: Face plate to cover unused front panel slots (required for all unused slots)

Package Checklist

• 1 TRC-190 with single power

input

• Power cord (for TRC-190-AC

only)

• 18 face plates

• User’s manual (printed)

• Warranty card

Dimensions

Unit: mm (inch)
