Features

y LFP(Link Fault Pass-through) and FEF(Far End Fault)

y Two different operation modes

¾ Store-and-Forward

¾ Pass Through

y Auto negotiation

y Support TS-1000 ver. 2

y Support Turbo Ring 2

y Plug and Play

y Hot-swap

Package Checklist

Moxa’s CSM-200 Series is shipped with the following items. If any of these

items is missing or damaged, please contact your customer service

representative for assistance.

y CSM-200 Series

y Hardware Installation Guide

y Warranty Card

NOTE: Please notify your sales representative if any of the above items are

missing or damaged.

Dimensions

CSM-200-1213

117.1 mm (4.61 in)

124.3 mm (4.89 in)

86.8 mm

(3.42 in)

21 mm

(0.83 in)

PWR

Fiber

Link

10M

100M
