Specifications

Technology

Standards IEEE 802.3 for 10BaseT,

IEEE 802.3u for 100BaseT(X), 100BaseFX

Interface

RJ45 ports 10/100BaseT(X)

Fiber ports 100BaseFX (SC/ST connector)

LED Indicators PWR, Fiber Link, 10/100M(TP port)

Optical Fiber

100BaseFX

Multi-mode Single-mode

Wavelength 1300 nm 1310 nm

Max. TX -10 dBm 0 dBm

Min. TX -20 dBm -5 dBm

RX Sensitivity -32 dBm -34 dBm

Link Budget 12 dB 29 dB

Typical Distance

5 km a

4 km b

40 km c

Saturation -6 dBm -3 dBm

a. 50/125 μm, 800 MHz*km fiber optic cable

b. 62.5/125 μm, 500 MHz*km fiber optic cable

c. 9/125 μm, 3.5 PS/(nm*km) fiber optic cable

Physical Characteristics

Housing SPCC

Dimensions 86.8 x 124.3 x 21 mm (3.42 x 4.89 x 0.83 in)

Weight Product only:

CSM-1213: 115 g (0.25 lb)

CSM-1214/1218: 125 g (0.28 lb)

Packaged:

CSM-1213: 170g (0.37 lb)

CSM-1214/1218: 180g (0.40 lb)

Environmental Limits

Operating Temperature 0 to 60°C (32 to 142°F)

Storage Temperature -20 to 75°C (-4 to 158°F)

Humidity 5 to 95 % RH

Power Requirements

Input Voltage 12 VDC

Power Consumption 180 mA @ 12 VDC

Regulatory Approvals

CE Class A

FCC Part 15 sub part B class A
