Moxa NA-4010 [4/6] Iologik 4000 expansion modules
![Moxa NA-4010 [4/6] Iologik 4000 expansion modules](/views2/1201171/page4/bg4.png)
4
www.moxa.com
info@moxa.com
Remote I/O
Digital Input Modules
Digital Output Modules
ioLogik 4000 Expansion Modules
M-1800: 8 digital inputs, sink type, 24 VDC
Digital Inputs: 8 channels
Type: sink
On-state Voltage: 24 VDC nominal, 11 to 28.8 VDC
Off-state Voltage: 0 to 5 VDC
On-state Current: 6 mA/point @ 28.8 VDC (max.)
Input Impedance: 5.1 kilo-ohms (typical)
Filtering Time: 1.5 ms (typical)
Common Type: External common (single common)
Input Current: 35 mA @ 5 VDC
Isolation: I/O to logic (photocoupler isolation)
Wiring: I/O cable max. 14 AWG
MTBF: 15,759,240 hrs (Standard: Telcordia SR332)
M-1801: 8 digital inputs, source type, 24 VDC
Digital Inputs: 8 channels
Type: source
On-state Voltage: 24 VDC nominal, 11 to 28.8 VDC
Off-state Voltage: 0 to 5 VDC
On-state Current: 6 mA/point @ 28.8 VDC (max.)
Input Impedance: 5.1 kilo-ohms (typical)
Filtering Time: 1.5 ms (typical)
Common Type: External common (single common)
Input Current: 35 mA @ 5 VDC
Isolation: I/O to logic (photocoupler isolation)
Wiring: I/O cable max. 14 AWG
MTBF: 15,811,800 hrs (Standard: Telcordia SR332)
M-1450: 4 digital inputs, 110 VAC
Digital Inputs: 4 channels, 110 VAC
On-state Voltage: 120 VAC nominal, 85 to 132 VAC
Off-state Voltage: 0 to 45 VAC
On-state Current: 8 mA/point @ 132 VAC (max.)
Input Impedance: 11 kilo-ohms (typical)
Common Type: 4 channels for 2 COMs (single common)
Input Current: 35 mA @ 5 VDC
Isolation: I/O to logic (photocoupler isolation)
Wiring: I/O cable max. 14 AWG
MTBF: 19,482,240 hrs (Standard: Telcordia SR332)
M-1451: 4 digital inputs, 220 VAC
Digital Inputs: 4 channels, 220 VAC
On-state Voltage: 240 VAC nominal, 170 to 264 VAC
Off-state Voltage: 0 to 45 VAC
On-state Current: 12 mA/point @ 264 VAC (max.)
Input Impedance: 22 kilo-ohms (typical)
Common Type: 4 channels for 2 COMs (single common)
Input Current: 35 mA @ 5 VDC
Isolation: I/O to logic (photocoupler isolation)
Wiring: I/O cable max. 14 AWG
MTBF: 19,727,520 hrs (Standard: Telcordia SR332)
M-1600: 16 digital inputs, sink type, 24 VDC
Digital Inputs: 16 channels
Type: sink
On-state Voltage: 24 VDC nominal, 11 to 28.8 VDC
Off-state Voltage: 0 to 5 VDC
On-state Current: 6 mA/point @ 28.8 VDC (max.)
Input Impedance: 5.1 kilo-ohms (typical)
Filtering Time: 1.5 ms (typical)
Common Type: 16 channels for 2 COMs (single common)
Input Current: 40 mA @ 5 VDC
Isolation: I/O to logic (photocoupler isolation)
Wiring: I/O flat cable 20-pin
MTBF: 11,659,560 hrs (Standard: Telcordia SR332)
M-1601: 16 digital inputs, source type, 24 VDC
Digital Inputs: 16 channels
Type: source
On-state Voltage: 24 VDC nominal, 11 to 28.8 VDC
Off-state Voltage: 0 to 5 VDC
On-state Current: 6 mA/point @ 28.8 VDC (max.)
Input Impedance: 5.1 kilo-ohms (typical)
Filtering Time: 1.5 ms (typical)
Common Type: 16 channels for 2 COMs (single common)
Input Current: 40 mA @ 5 VDC
Isolation: I/O to logic (photocoupler isolation)
Wiring: I/O flat cable 20-pin
MTBF: 11,694,600 hrs (Standard: Telcordia SR332)
M-2800: 8 digital outputs, sink type, 24 VDC, 0.5 A
Digital Outputs: 8 channels
Type: sink
Output Range: 24 VDC nominal
On-state Voltage Drop: 0.3 VDC @ 25°C (max.)
On-state Current: 1 mA per channel (min.)
Off Leakage Current: 50 μA (max.)
Current Rating: 0.5 A per channel
Common Type: 8 channels per external common (single common)
Input Current: 60 mA @ 5 VDC
Isolation: I/O to logic (photocoupler isolation)
Wiring: I/O cable max. 14 AWG
MTBF: 13,884,600 hrs (Standard: Telcordia SR332)
M-2801: 8 digital outputs, source type, 24 VDC, 0.5 A
Digital Outputs: 8 channels
Type: source
Output Range: 24 VDC nominal
On-state Voltage Drop: 0.3 VDC @ 25°C (max.)
On-state Current: 1 mA per channel (min.)
Off Leakage Current: 50 μA (max.)
Current Rating: 0.5 A per channel
Common Type: 8 channels per external common (single common)
Input Current: 60 mA @ 5 VDC
Isolation: I/O to logic (photocoupler isolation)
Wiring: I/O cable max. 14 AWG
MTBF: 14,340,120 hrs (Standard: Telcordia SR332)
