Moxa NA-4010 [6/6] Modular i o accessories

6

Remote I/O

© Moxa Inc. All Rights Reserved. Updated Mar. 1, 2016. Specifications subject to change without notice. Please visit our website for the most up-to-date product information.

M-7001: System power module

System Input Voltage: 24 VDC, 11 to 28.8 VDC

Field Power Input Voltage: 24 VDC (±20%)

Current for I/O Modules: 1.5 A @ 5 VDC (max.)

System Bus Output Voltage: 5 VDC (max.)

Field Power Contacts Current: 10 A (max.)

Dimensions: 77.5 x 67.5 x 51 mm

(3.05 x 2.66 x 2.01 in)

Compliance: RoHS compliant

M-7804: 0 VDC

Channels: 8

Mode: 0 VDC

MTBF: 73,750,440 hrs (Standard: Telcordia SR332)

M-8001-PK: Removable terminal block

Usage: Terminal block for the ioLogik 4000 series

Packaging: 9 pcs in one box

M-7002: Field power module

Field Power Input Voltage:

• DC: 5 VDC, 24 VDC, 48 VDC

• AC: 110 VAC, 220 VAC

Current for Field Power Contacts: 10 A (max.)

MTBF: 75,528,720 hrs (Standard: Telcordia SR332)

M-7805: 24 VDC

Channels: 8

Mode: 24 VDC

MTBF: 73,750,440 hrs (Standard: Telcordia SR332)

Markers: For the ioLogik 4000 series

M-8003-PK: Markers with 0 to 9 numbering; 100 pcs per box

M-8004-PK: Blank markers; 100 pcs per box

Available Models

M-1800: Modular remote I/O module with 8 DIs, sink type, 24 VDC, RTB, -10 to 60°C operating temperature

M-1801: Modular remote I/O module with 8 DIs, source type, 24 VDC, RTB, -10 to 60°C operating temperature

M-1600: Modular remote I/O module with 16 DIs, sink type, 24 VDC, 20-pin, -10 to 60°C operating temperature

M-1601: Modular remote I/O module with 16 DIs, source type, 24 VDC, 20-pin, -10 to 60°C operating temperature

M-1450: Modular remote I/O module with 4 DIs, 110 VAC, RTB, -10 to 60°C operating temperature

M-1451: Modular remote I/O module with 4 DIs, 220 VAC, RTB, -10 to 60°C operating temperature

M-2800: Modular remote I/O module with 8 DOs, sink type, 24 VDC, RTB, -10 to 60°C operating temperature

M-2801: Modular remote I/O module with 8 DOs, source type, 24 VDC, RTB, -10 to 60°C operating temperature

M-2600: Modular remote I/O module with 16 DOs, sink type, 24 VDC, 20-pin, -10 to 60°C operating temperature

M-6200: Modular remote I/O module with 2 RTDs, RTB, -10 to 60°C operating temperature

M-6201: Modular remote I/O module with 2 TCs, RTB, -10 to 60°C operating temperature

M-7001: Modular remote I/O module with 24 VDC system power input, RTB, -10 to 60°C operating temperature

M-7002: Modular remote I/O module with 5/24/48 VDC or 110/220 VAC field power input, RTB, -10 to 60°C operating temperature

M-7804: Modular remote I/O module with 8 channels 0 VDC output, RTB, -10 to 60°C operating temperature

M-7805: Modular remote I/O module with 8 channels 24 VDC output, RTB, -10 to 60°C operating temperature

Optional Accessories

TB 1600: Screw-locking terminal block with 20-pin connector for DIN-rail mounting

20-to-20-pin flat cable: 20-pin to 20-pin flat cable, 500 mm

M-8001-PK: Removable terminal block, 9 pcs per pack
