ioPAC 8500 Hardware Introduction
1-2
Overview
The ioPAC 8500 modular type controllers use an ARM9 based industrial grade CPU for the system, with ARM
Cortex™ M4 based CPUs used for the modules. The controllers have 2, 5, or 9 I/O slots for 85M series modules.
The USB bus between the controller CPU and module CPUs transmits data at up to 200 Mbps, and the dual CPU
architecture supports a 40 kHz analog input sampling rate, pre-recording of analog input data, and millisecond
timestamp. The ioPAC 8500 supports C/C++ and IEC 61131-3 programming capability, rail-level surge and
ESD protection, a -40 to 75°C operating temperature range, anti-vibration, hot-swappability of modules, two
10/100 Mbps Ethernet ports with two MACs (Port Trunking ready), and two 3-in-1 serial ports. With Moxa’s
Active OPC Server and DA-Center, the ioPAC 8500 series provides a comprehensive solution for data
acquisition and control applications in harsh environment.
Package Checklist
ioPAC 8500
The ioPAC 8500 ships with the following items:
• ioPAC 8500 controller
• Serial console cable (C/C++ models only)
• Documentation and software CD
85M Modules
85M modules ships with the following items:
• 85M module
• DB44 to 4-port DB9 cable included in 85M-5401-T package
Optional Accessories (can be purchased separately)
• WK-75: Wallmount kit
• CBL-M12D(MM4P)/RJ45-100 IP67: M12 to RJ45 cable
• 85M-BKTES: Empty slot cover for ioPAC 85xx modules (3 pcs per package)
