- 11 -
LED Indicators
The front panel of the WDR-3124A contains several LED indicators. The
function of each LED is described in the table below.
LED
Color
State
Description
Front Panel LED Indicators (System)
PWR1 Green
On
Power is being supplied from power input 1
Off
Power is not being supplied from power
input 1.
PWR2 Green
On
Power is being supplied from power input 2
Off
Power is not being supplied from power
input 2.
STATE Green
On
System startup is complete and the system
is operating
Blinking
Device has been located by the Wireless
Search Utility
Off
Power is off, or the system is booting up
FAULT Red
On
System configuration error or a relay event
has occurred
Blinking
(fast)
(Blinking interval: 0.5 sec) IP address
conflict.
Blinking
(slow)
(Blinking interval: 1 sec) Cannot get an IP
address from a DHCP server.
Off
Power is off, or there is no error condition.
CELLULAR
SIGNAL (3
LEDs)
Green On
Number of LEDs to indicate cellular signal
level when connected to a cellular network
with an IP address.
Signal LED 1: 0 < RSSI <= 12
Signal LED 2: 12 < RSSI <= 20
Signal LED 3: 20 < RSSI <= 31
WIFI
SIGNAL (3
LEDs)
Green On/Off
WiFi signal level (Client-Router mode only)
Signal LED 1: 0 < SNR <= 23
Signal LED 2: 23 < SNR <= 47
Signal LED 3: 47 < SNR
SIM1 Amber
On/Off
SIM 1 is active or inactive
Blinking
SIM 1 is not inserted or PIN code is incorrect
SIM2 Amber
On/Off
SIM 2 is active or inactive
Blinking
SIM 2 is not inserted or PIN code is incorrect
2G Amber
On
Registered to a base station with cellular
connection in GPRS or EDGE mode
3G Amber
On
Registered to a base station with cellular
connection in UMTS or HSPA mode
GPS Green
On
GPS has been located
Blinking
Locating GPS or less than four satellites have
been located.
Off
GPS has not been located
LAN Port LED Indicators (Port Interface)
1000M Green
On
1000Mbps link is active
Blinking
Data is being transmitted at 1000Mbps
Off
1000Mbps link is inactive
10/100M Amber
On
10/100Mbps link is active
Blinking
Data is being transmitted at 10/100Mbps
Off
10/100Mbps link is inactive
