Moxa VPort 26A-1MP Getting Started
2-4
d) Connect the cables to the IP camera module’s connectors.
Connect the Ethernet cable to RJ45 Ethernet port, as well as the terminal blocks with power line and
DI/DO/Audio lines (if used).
NOTE
Be sure to arrange the cables carefully to make sure that all cables are connected properly. We recommend
connecting the Ethernet cable first, and then the 9
-pin terminal block. Connect the 2-pin terminal block last.
NOTE
The conduit hole must face downward to provide the VPort 26A
-1MP with IP66 protection against rain when
installed in an outdoor environment.
