![Moxa VPort 26A-1MP-T [65/82] Schedule](/views2/1201823/page65/bg41.png)
Moxa VPort 26A-1MP System Configuration
4-37
Send Alarm with Snapshot images
Setting Description Default
Take snapshot
seconds(s) before the
event
A snapshot image is taken this number of seconds before the
event alarm is triggered.
2 seconds
(from 1 to 6
seconds)
Take snapshot
seconds(s) after the
event
A snapshot image is taken this number of seconds after the
event alarm is triggered.
11 seconds
(from 1 to 999
seconds)
NOTE
VPort
products will take 3 JPEG snapshot images: VPRE.JPG (pre-
event), VTRG.JPG (the moment of event) and
VPOS.JPG (post
-
event) for the video channel when the trigger condition is met. The three snapshots can also
be downloaded by Email and FTP.
Suffix of Image File Name in FTP and Mail attachment
The snapshot images can be sent either by email or FTP. Administrators can add a suffix to the filename of each
JPEG snapshot image to make it easier to identify the files when using FTP to download the snapshots.
Setting Description Default
With Date and Time Enable or disable adding the date and time to the filename. Disable
With Customized words
Enable or disable adding some additional custom text to the
filename to identify the snapshot image.
Disable
DI, Relay Status
Administrators can check the current DI and Relay status of the VPort in the “DI, Relay Status” section on the
“Event Alarm Basic Settings” page. Two options are available to return the relay’s status back to the system
defaults. To enable the function, check the Override Relay 1 warning setting box, and then click on Save.
In addition, in the “Relay Active behavior” section, you can configure the duration of the relay action, with
options of activating the relays continuously, for the specified Alarm Interval Time, or for the period of time
when the alarm is triggered.
Schedule
A schedule is provided to set event alarms for daily security applications.
