B. Modbus Address Table
Read/Write Registers (Support Function Code 4 & Function Code 3)
Address Word (2 bytes)
Item name R/W Description
0x0000 1 Vender ID R 0x1393
0x0001 1 Unit ID R 0x01
0x0002 1 Product Code R 0x880E
0x0010 20 Vender Name R moxa
0x0030 20 Product Name R VPort 36-1MP
0x0050 1 Serial Number R
0x0051 2 Firmware Version R
0x0053 2 Release Date R
0x0055 2 MAC Address R
0x0080 1 DI Status R 1: High
0: Low
0x0084 1 Relay Status R/W 0: Open
1: Close
0x0701 1 Record Status R/W R:
0: No record
1: recording
W:
0: stop record
1: start record
0x0801 1 Dynastream Status R/W R
0: No run dynastream
1: run dynastream
W
0: stop dynastream
1: start dynastream
0x0802 1 IVA Tamper Status R/W 0x0000: No alert
0x0001: Alert
0x0803 1 IVA Learning Status R 0x0000: No learning
0x0001: Is learning
0x0804 1 IVA Item 01 Status R/W 0x0000: No alert
0x0001: Alert
0x0805 4 IVA Item 01 Object detected
coordination
R Word 0: Left Top X
Word 1: Left Top Y
Word 2: Right Down X
Word 3: Right Down Y
0x0809 1 IVA Item 02 Status R/W 0x0000: No alert
0x0001: Alert
0x080A 4 IVA Item 02 Object detected
coordination
R Word 0: Left Top X
Word 1: Left Top Y
Word 2: Right Down X
Word 3: Right Down Y
