Section 2 - Getting Started

Dynamic and Static IP Addressing on the AP

When you power on the access point, the built-in DHCP client searches for a DHCP server on the network in order

to obtain an IP Address and other network information. If the AP does not nd a DHCP server on the network, the AP

continues to use its default Static IP Address (10.90.90.91) until you re-assign it a new static IP address (and specify a

static IP addressing policy) or until the AP successfully receives network information from a DHCP server.

To change the connection type and assign a static IP address by using the CLI, see “Conguring the Ethernet

Settings” on page 18 or, by using the Web UI, see “Ethernet Settings” on page 35.

Caution! If you do not have a DHCP server on your internal network, and do not plan to use one,

the rst thing you must do after powering on the access point is change the connection type from

DHCP to static IP. You can either assign a new static IP address to the AP or continue using the

default address. We recommend assigning a new static IP address so that if you bring up another

WLAN AP on the same network, the IP address for each AP will be unique.

Recovering an IP Address

If you experience trouble communicating with the access point, you can recover a static IP address by resetting the AP

conguration to the factory defaults (see “Resetting the Factory Default Conguration” on page 81), or you can get

a dynamically assigned address by connecting the AP to a network that has a DHCP server.

Discovering a Dynamically Assigned IP Address

If you have access to the DHCP server on your network and know the MAC address of your AP, you can view the new

IP address associated with the MAC address of the AP.

If you do not have access to the DHCP server that assigned the IP address to the AP or do not know the MAC address

of the AP, you might need to use the CLI to nd out what the new IP address is. For information about how to discover

a dynamically assigned IP address, see “Using the CLI to View the IP Address” on page 17.

Installing the UAP

To access the Administration Web UI, you enter the IP address of the AP into a Web browser. You can use the default

IP address of the AP (10.90.90.91) to log on to the AP and assign a static IP address, or you can use a DHCP server

on you network to assign network information to the AP. The DHCP client on the AP is enabled by default.

To install the UAP, use the following steps:

1.) Connect the AP to an administrative PC by using a LAN connection or a direct-cable connection.

•) To use a LAN connection, connect one end of an Ethernet cable to the network port on the access point and

the other end to the same hub where your PC is connected, as shown in the following gure.

The hub or switch you use must permit broadcast signals from the access point to reach all other devices on

the network.
