Unied Access Point Administrator’s Guide

Page 80

March 2012

Section 7 - Maintaining the Access Point

Figure 46 - Conrmation Prompt

3.) To proceed with the download, select OK.

A dialog box opens allowing you to view or save the le.

4.) Select the Save File option and select OK.

5.) Use the le browser to navigate to the directory where you want to save the le, and click OK to save the le.

You can keep the default le name (cong.xml) or rename the backup le, but be sure to save the le with an

.xml extension.

Restoring the Conguration from a Previously Saved File

You can use HTTP or TFTP to transfer les to and from the UAP. After you download a conguration le to the

management station, you can manually edit the le, which is in XML format. Then, you can upload the edited

conguration le to apply those conguration settings to the AP.

Use the following procedures to restore the conguration on an AP to previously saved settings by using TFTP:

1.) Select TFTP for Upload Method.

Figure 47 - Manage this Access Point’s Conguration - Restore (TFTP)

2.) Enter a name (1 to 63 characters) for the backup le in the Filename eld, including the .xml le name extension

and the path to the directory that contains the conguration le to upload.

3.) Enter the IP address of the TFTP server in the Server IP eld.

4.) Click the Restore button.

The AP reboots. A reboot conrmation dialog and follow-on rebooting status message displays. Please wait for

the reboot process to complete, which might take several minutes.

The Administration Web UI is not accessible until the AP has rebooted.

Use the following steps to save a copy of the current settings on an AP to a backup conguration le by using HTTP:

1.) Select HTTP for Upload Method.

Figure 48 - Manage this Access Point’s Conguration - Restore (HTTP)
