Replacing the exhaust filter

You must replace the exhaust filter in your vacuum cleaner

once a year.

Replacing the micro-hygiene filter

Figure

䡲

Open the dust bag compartment lid (see Figure 18).

䡲

Release the filter holder by pressing the locking tab in the

direction of the arrow

䡲

Remove the foam filter and micro-hygiene filter.

Insert the new micro-hygiene filter and foam filter into the

filter holder.

䡲

Insert the filter holder into the vacuum cleaner and clip

into place.

Replacing the HEPA filter

You can order a new filter from our after-sales service

using the following replacement part number: 574 020

Figure

䡲 Open the dust bag compartment lid (see Figure 18).

䡲 Release the HEPA filter by pressing the locking tab in the

direction of the arrow and remove it from the vacuum

cleaner (see Figure 23).

䡲 Insert the new HEPA filter and clip into place.

If you have used the vacuum cleaner for fine dust parti-

cles (such as plaster or cement), clean the motor pro-

tection filter by tapping it and, if necessary, replace the

motor protection filter and the exhaust filter.

Care

Always switch off the vacuum cleaner and disconnect the

power cord from the mains before cleaning the vacuum

cleaner.

The vacuum cleaner and plastic accessories can be cleaned

with a commercial plastic cleaner.

Do not use a scourer, glass-cleaning agent or all-

purpose cleaning product.

Never immerse the vacuum cleaner in water.

The dust compartment can, if necessary, be cleaned with a

second vacuum cleaner or simply wiped with a dry cloth or

dusting brush.

Subject to technical modifications.

24*

23*

Cleaning the motor protection filter

The motor protection filter should be cleaned regularly by

knocking out the dirt and rinsing.

Figure

䡲

Open the dust bag compartment lid (see Figure 18).

䡲

Pull out the motor protection filter in the direction of the

arrow.

䡲

Clean the motor protection filter by tapping it.

䡲

If it is very dirty, the motor protection filter should be

rinsed.

The filter must then be left to dry for at least 24 hours.

䡲

After cleaning, slide the motor protection filter into the

vacuum cleaner and close the dust bag compartment lid.

Cleaning the foam filter

If your appliance is fitted with a filter frame and foam

filter, the foam filter should be cleaned at regular

intervals by tapping out the dust or rinsing the filter.

Figure

Open the dust bag compartment lid (see Fig. 18).

Pull out the filter frame and foam filter in the

direction of the arrow.

Remove the foam filter from the filter frame and

clean it by tapping out the dust.

If the foam filter is very dirty, it should be rinsed.

After rinsing it, allow the foam filter to dry for at

least 24 hours.

After cleaning, place the foam filter back in the filter

frame, insert the filter frame with foam filter in the

appliance and close the dust bag compartment lid.

Replacing the HEPA filter (motor protection filter)

If your vacuum cleaner is equipped with a HEPA filter, this

should be replaced once a year.

Figure

䡲

Open the dust bag compartment lid.

䡲

Pull out the HEPA filter in the direction of the arrow and

remove it from the appliance.

䡲

Insert the new HEPA filter and close the dust bag

compartment lid.

22*

21*

20*
