Bosch BGL 452132 [12/143] Changing the dust bag and filters

Figure

Hard-floor brush

䡲 For cleaning hard floor coverings

(tiles, parquet flooring, etc.)

䡲 Connect the floor tool and the telescopic tube together.

Figure

Once you have switched off the vacuum cleaner, you can

use the parking aid on the back of the vacuum cleaner if

you wish to stop vacuuming for a short time.

To do this, slide the catch on the floor tool into the

groove on the back of the vacuum cleaner.

When the work is done

Figure

䡲 Unplug the vacuum cleaner.

䡲 Briefly pull the power cord and release. The cord rewinds

automatically.

Figure

To store or transport the vacuum cleaner, use the storage

aid on the underside of the vacuum cleaner.

Stand the vacuum cleaner up on its end. Slide the catch

on the floor tool into the groove on the underside of the

vacuum cleaner.

Changing the dust bag and filters

Replacing the dust bag

Figure

If the dust bag change indicator lights up brightly and

evenly when the floor tool is lifted from the carpet and

the highest suction power is selected, the dust bag must

be changed, even though it may not yet be full. In this

case it is essential to change the dust bag due to the

type of material it contains.

First check that the nozzle, suction pipe and flexible hose

are not blocked, as this would also lead to the dust bag

change indicator being triggered.

Figure

Open the lid by moving the locking lever in the direction

of the arrow.

Figure

a) Seal the dust bag by pulling the sealing strip and then

remove it.

b) Insert a new dust bag into the holder and close the dust

bag compartment lid.

Caution: the lid will only close when the dust bag is

inserted.

13*

Vacuuming

Figure

The required suction power can be selected infinitely

variably by adjusting the slide control.

䡲 Lowest

suction range:

For vacuuming delicate fabrics,

e.g. curtains.

䡲 Low

suction range:

For daily vacuuming of lightly soiled floors.

䡲 Medium

suction range:

For vacuuming durable floor coverings, hard floors and

for heavily soiled surfaces.

䡲 High

suction range:

For vacuuming stubborn dirt and very heavily soiled

surfaces.

Figure

Adjusting the floor tool:

a) For vacuuming rugs

and carpets =>

b For vacuuming

hard floors =>

Caution!

Floor tools are subject to a certain amount of wear,

depending on the type of hard floors you have

(e.g. rough, rustic tiles). Therefore, you must check

the underside of the floor tool at regular intervals.

Worn undersides of floor tools may have sharp edges

that can damage sensitive hard floors, such as parquet

or linoleum. The manufacturer does not accept any

responsibility for damage caused by worn floor tools.

Turbo brush

If your vacuum cleaner is equipped with a turbo brush,

please consult the accompanying instruction manual for

notes on its use and maintenance.

Figure Vacuuming with accessories

Attach the nozzles to the tube or handle as required:

a) Crevice nozzle for vacuuming crevices and corners, etc.

b) Upholstery nozzle for vacuuming upholstered furniture,

curtains, etc.

Figure

Pet hair tool

䡲 Floor tool for easy and thorough vacuuming of pet hair.

䡲 Push the telescopic tube into the connecting piece of the

pet hair tool until it engages.

Press on the locking collar and pull out the telescopic

tube to disconnect.

䡲 To clean, simply vacuum the tool using the suction

pipe/telescopic tube.

12*

11*

Dependent on model
