Braun SI 6591 [10/70] G cleaning the anticalc valve

G Cleaning the anticalc valve

The iron’s anticalc valve is located at the

lower end of the steam button (3). It has

to be decalcified regularly (e.g. when the

steam development is insufficient).

Proceed as follows:

1) Unplug the iron and empty the water tank.

2) Press the steam button so it is lifted.

3) Remove carefully (some water may now

leak from the sole plate).

4) Do not touch the anticalc valve.

5) Immerse in vinegar (not vinegar essence)

or lemon juice until the lime becomes soft.

6) Use a non-metallic brush until all openings

are clean.

7) Rinse under running water.

8) Re-insert the steam button.

9) Press to check the steam on/off function.

Note:

the iron must never be used without

the steam button.

H Decalcifying /anticalc system

When scale particles come out of the steam

vents or when the steam development is

insufficient even after cleaning the anticalc

valve, you should clean the steam chamber

as follows:

1) Make sure the steam button is in its lower

position.

2)–3) Fill water into the tank, connect to the

mains and select the «•••» temperature

setting.

4)–5) Wait until the pilot light turns off.

Unplug the iron.

6)–7) Hold the iron over a sink, then press the

steam button so it is lifted, carefully pull it

up, turn it and rest it in this position.

Caution:

When the steam button is pulled

up, hot water and steam will come out from

the sole plate.

8) Push back the steam button until it catches

in the lower position.

9)–10) Fill water into the tank, connect to the

mains and select the «•••» temperature

setting.

11)–13) When the pilot light goes off, press

the power shot button 4 times to rinse the

iron. Disconnect the iron and wait for the

sole plate to cool off, then clean it as

described above in section «G».

Note:

the iron must never be used without

the steam button.

I Trouble-shooting guide

Problem Remedy

––––––––––––––––––––––––––––––––––––––

Drops Turn the steam regulator

coming out counter-clockwise to

of the steam reduce the steam or

vents press the steam button

to turn the steam off.

Take longer intervals

when pressing the power

shot button.

Select a higher tempera-

ture setting.

No steam Press the steam button

at all so that it is lifted.

Less steam Clean the anticalc valve

develops or (see «G»).

no steam at all

Calcium par- Decalcify the steam

ticles coming chamber (see «H»).

through the

steam vents

––––––––––––––––––––––––––––––––––––––

Subject to change without notice.

This product conforms to the

European Directives EMC 2004/108/

EC and Low Voltage 2006/95/EC.

Please do not dispose of the

product in the household waste

at the end of its useful life. Disposal

can take place at a Braun Service

Centre or at appropriate collection

points provided in your country.

3674350_SI6000_S6-72 Seite 10 Montag, 25. Februar 2008 9:36 09
