![Makita BDF 460 SJE [6/32] English](/views2/1020783/page6/bg6.png)
6
ENGLISH
Explanation of general view
1Button
2 Battery cartridge
3Terminal cover
4 Charging light
5 Grip base
6Teeth
7 Side grip
8 Loosen
9 Tighten
10 Depth rod
11 Thumb screw
12 Sleeve
13 Bit
14 Bit holder
15 Switch trigger
16 Reversing switch lever
17 A side
18 B side
19 Clockwise
20 Counterclockwise
21 Low speed
22 High speed
23 Speed change lever
24 Graduations
25 Adjusting ring
26 Drill marking
27 Pointer
28 Limit mark
29 Brush holder cap
30 Screwdriver
SPECIFICATIONS
Model BDF460
Capacities
Steel ...................................................................13 mm
Wood ..................................................................38 mm
Wood screw .......................................... 10 mm x 90 mm
Machine screw .....................................................6 mm
No load speed (min
-1
)
High ................................................................0 – 1,500
Low ....................................................................0 – 460
Overall length ......................................................259 mm
Net weight
(with battery cartridge) ...........................................2.6 kg
Rated voltage ....................................................D.C.24 V
• Due to our continuing program of research and devel-
opment, the specifications herein are subject to change
without notice.
• Note: Specifications may differ from country to country.
SAFETY INSTRUCTIONS
WARNING! When using battery operated tools
basic safety precautions, including the following,
should be followed to reduce the risk of fire, leak-
ing batteries and personal injury: Read these
instructions before operating this product and
save these instructions.
For safe operation:
1. Keep work area clean
– Cluttered areas and benches invite injuries.
2. Consider the work environment.
– Do not expose the tool to rain. Keep work area
well lit. Do not use tools in the presence of
flammable liquids or gases.
3. Keep children away
– Do not let visitors touch the tool. Keep visitors
away from work area.
4. Store batteries or idle tools
– When not in use, tools and batteries should be
stored separately in a dry, high or locked up
place, out of reach of children.
–Ensure that battery terminals cannot be
shorted by other metal parts such as screws,
nails, etc.
5. Do not force the tool
– It will do the job better and safer at the rate for
which it was intended.
6. Use the right tool
– Do not force small tools or attachments to do
the job of a heavy duty tools. Do not use tools
for purposes not intended.
7. Dress properly
– Do not wear loose clothing or jewellery, they
can be caught in moving parts. Non-skid foot-
wear is recommended when working out-
doors. Wear protecting hair covering to
contain long hair.
8. Use protective equipment
– Use safety glasses and if the cutting operation
is dusty, a face or dust mask.
9. Connect dust extraction equipment
– If devices are provided for the connection of
dust extraction and collection ensure these
are connected and properly used.
10. Do not abuse the supply cord (if fitted)
– Never carry the tool by the cord or yank it to
disconnect from the socket. Keep the cord
away from heat, oil and sharp edges.
11. Secure the work
– Use clamps or a vice to hold the work. It is
safer than using your hand and it frees both
hands to operate the tool.
12. Do not over-reach
– Keep proper footing and balance at all times.
13. Maintain tools with care
– Keep cutting tools sharp and clean for better
and safer performance. Follow instructions for
lubrication and changing accessories. Inspect
tool cords periodically and if damaged have
repaired by an authorized service facility.
14. Disconnect tools
– Where the design permits, disconnect the tool
from its battery pack when not in use, before
servicing and when changing accessories
such as blades, bits and cutters.
15. Remove adjusting keys and wrenches
– Form the habit of checking to see that keys and
adjusting wrenches are removed from the tool
before turning it on.
