1-8
Gettng Started
Back Panel Quck Gude
Mouse
PS/2
®
mouse DIN connector for a PS/2
®
mouse.
Keyboard
PS/2
®
keyboard DIN connector for a PS/2
®
keyboard.
USB 2.0 Port
The USB 2.0 port s for attachng USB 2.0 devces such as keyboard, mouse, or other
USB 2.0-compatble devces.
USB 3.0 Port (FM2-A85XMA-P33/ FM2-A75MA-P33)
USB 3.0 port s backward-compatble wth USB 2.0 devces. It supports data transfer
rate up to 5 Gbt/s (SuperSpeed).
Important
In order to use USB 3.0 devces, you must connect to a USB 3.0 port. If a USB cable s
used, t must be USB 3.0 complant.
▶
▶
▶
▶
LAN
Lne-In
Lne-Out
Mc
USB 2.0 Port
VGA Port
DVI-D Port
Mouse
USB 2.0 Port
USB 3.0 Port
(FM2-A85XMA-P33/
FM2-A75MA-P33)
USB 2.0 Port
(FM2-A55M-P33)
Keyboard
