2-11
MS-7721
Chapter 2
operate under the default number of cores. When set to [Manual], you wll be able to
enable/dsable the specc CPU core.
AMD Turbo Core Technology
Ths technology automatcally ncreases the frequency of actve CPU cores to mprove
performance.
Adjust Max Turbo Core Rato
Ths tem s used to adjust Max Turbo Core rato
Adjusted Max Turbo Core Frequency
It shows the adjusted Max Turbo Core frequency. Read-only.
Adjust Turbo Core Rato
Ths tem s used to adjust Turbo Core rato.
Adjusted Turbo Core Frequency
It shows the adjusted Turbo Core frequency. Read-only.
Adjust GPU Engne Frequency
Ths tem s used to adjust the ntegrated graphcs frequency.
Adjusted GPU Engne Frequency
It shows the adjusted ntegrated graphcs frequency. Read-only.
DRAM Frequency
Ths tem allows you to adjust the DRAM frequency. Please note the overclockng
behavor s not guaranteed.
Adjusted DRAM Frequency
It shows the adjusted DRAM frequency. Read-only.
Intel Extreme Memory Prole (XMP)
Choose to apply an Intel Extreme Memory Prole (XMP) to ncrease system performance.
When the Intel Extreme Memory Prole (XMP) s enabled, the AMD Memory Prole
(AMP) wll be forced to be dsabled.
AMD Memory Prole (AMP)
Choose to apply an AMD Memory Prole (AMP) to ncrease system performance. When
AMD Memory Prole (AMP) s enabled, the Intel Extreme Memory Prole (XMP) wll be
forced to be dsabled.
DRAM Tmng Mode
Select whether DRAM tmng s controlled by the SPD (Seral Presence Detect)
EEPROM on the DRAM module. Settng to [Auto] enables DRAM tmngs and the
followng “Advanced DRAM Conguraton” sub-menu to be determned by BIOS based
on the conguratons on the SPD. Selectng [Lnk] or [Unlnk] allows users to congure
the DRAM tmngs for each channel and the followng related “Advanced DRAM
Conguraton” sub-menu manually.
Advanced DRAM Conguraton
Press <Enter> to enter the sub-menu.
Command Rate
Ths settng controls the DRAM command rate.
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
