![MSI B75MA-G43 [51/76] Chapter 2](/views2/1208976/page51/bg33.png)
2-11
MS-7798
Chapter 2
OC
Important
Overclockng your PC manually s only recommended for advanced users.
Overclockng s not guaranteed, and f done mproperly, can vod your warranty or
severely damage your hardware.
If you are unfamlar wth overclockng, we advse you to use OC Gene for easy
overclockng.
Current CPU/ DRAM Frequency
These tems show the current clocks of CPU and Memory speed. Read-only.
Adjust CPU Rato
Controls the multpler that s used to determne nternal clock speed of the processor.
Ths feature can only be changed f the processor supports ths functon.
Adjusted CPU Frequency
It shows the adjusted CPU frequency. Read-only.
Adjust CPU Rato n OS
Enable ths tem to allow CPU rato changes n the OS by usng MSI Control Center II.
EIST
Enhanced Intel SpeedStep technology allows you to set the performance level of the
mcroprocessor whether the computer s runnng on battery or AC power. Ths eld only
appears wth nstalled CPUs that support ths technology.
Intel Turbo Boost
Enables or dsables Intel Turbo Boost whch automatcally boosts CPU performance
above rated speccatons (when applcatons requests the hghest performance state
of the processor).
•
•
•
▶
▶
▶
▶
▶
▶
