MSI B75MA-G43 [57/76] Chapter 2
![MSI B75MA-G43 [57/76] Chapter 2](/views2/1208976/page57/bg39.png)
2-17
MS-7798
Chapter 2
ECO
Important
Once you clck the “ECO” button n the pre-set area, some tems n ECO menu wll be
xed and un-adjustable.
EuP 2013
Energy Usng Products Lot 6 2013 (EUP) reduces power consumpton when system s
o or n standby mode.
Note: When enabled, the system wll not support RTC wake up event functons.
C1E Support
To enable ths tem to reduce the CPU power consumpton whle dle. Not all processors
support Enhanced Halt state (C1E).
Intel C-State
C-state s a power management state that detects when the system s dle and lowers
power consumpton accordngly.
Package C State lmt
Ths eld allows you to select a C-state mode.
CPU Core Voltage/ CPU I/O Voltage/ GPU Voltage/ DRAM Voltage/ 3.3V/ 5V/ 12V
These tems show the voltages. Read only.
▶
▶
▶
▶
▶
