Philips SCD570/00 [10/148] English

Sensitivity levels and indications

Icon Sensitivity Description

highest Hear everything from your baby. The speaker of the

parent unit is continuously on.

high Hear all sounds from soft babbling and louder. If your

baby does not make any sound, the speaker of the parent

unit is off.

medium Hear sounds from soft cries and louder. If your baby

makes softer sounds, the speaker of the parent unit does

not go on.

low The speaker of the parent unit only goes on if the baby

makes loud sounds, for instance because it is crying.



Smart Eco is a standard feature on this baby monitor. It automatically reduces the DECT signal from

the baby unit to save energy. To save even more energy, activate the Eco Max mode. In this mode,

the DECT signal of the baby unit is switched off as long as the baby does not make a sound.

Caution: When the baby makes a sound, there may be a slight delay in response because the

DECT signal has to switch on again before the baby unit can send feedback to the parent unit.



- In Eco Max mode you do not receive feedback when the parent unit is out of range of the

baby unit. You can check the link by pressing any button on the parent unit.

- You cannot switch on the Eco Max mode if the microphone sensitivity is set to level 4.



1 Select ‘Eco Max’ in the menu with the + and - buttons and press OK to conrm.

2 When the display shows ‘Turn On’, press OK to switch on the Eco Max mode.

3 The warning message ‘!No alert if out of range, OK?’ appears on the display. Press OK to

conrm.

Note: The warning message scrolls across the display twice. If you do not press OK, the parent unit leaves

the menu and the Eco Max mode remains off.

, The Eco Max indication ashes on the display and the ‘link’ light ashes green slowly (Fig. 13).

, When the parent unit receives a DECT signal from the baby unit because the baby makes a

sound, the ‘link’ light turns solid green.



1 Press the MENU button

2 Use the + and - buttons to select ‘Eco Max’ and press OK to conrm.

3 When the display shows ‘Turn Off’, press OK to conrm.

ENGLISH10
