Philips SCD570/00 [7/148] English

Linking parent unit and baby unit

1 Press and hold the 3 button on the baby unit for 2 seconds until the power-on light goes on.

2 Press and hold the 3 button on the parent unit for 2 seconds until the display lights up.

, The ‘link’ light on the parent unit starts ashing red and the message ‘I AM LINKING’ appears

on the display.

, When the parent unit and baby unit are linked, the ‘link’ light turns solid green. The signal

strength indicator and the message ‘LINKED’ appear on the display.

, If no connection is established, the message NOT LINKED is displayed and the parent unit

starts to beep.

What to do if no link is established

- If the parent unit is out of range, place it closer to the baby unit, but not closer than

1 metre/3.5 feet.

- If the baby or parent unit is too close to another DECT appliance (e.g. a cordless phone),

switch off this appliance or move the unit away from this appliance.

- If the baby unit is switched off, switch it on.

Operating range

- The operating range is 330 metres/1000 feet outdoors and up to 50 metres/150 feet indoors.

- The operating range of the baby monitor varies depending on the surroundings and factors that

cause interference. Wet and moist materials cause so much interference that the range loss is up

to 100%. For interference from dry materials, see table below

Dry materials Material thickness Loss of range

Wood, plaster, cardboard, glass

(without metal, wires or lead)

< 30cm (12in) 0-10%

Brick, plywood < 30cm (12in) 5-35%

Reinforced concrete < 30cm (12in) 30-100%

Metal grilles or bars < 1cm (0.4in) 90-100%

Metal or aluminium sheets < 1cm (0.4in) 100%

Functions and feedback on the baby unit

Nightlight

The nightlight produces a soft glow that comforts your baby.

1 Press the Q button on the baby unit to switch on the nightlight.

2 Press the Q button again to switch off the nightlight.

Lullaby function

1 Press the K button on the baby unit to play the last selected lullaby. (Fig. 2)

, The selected lullaby repeats for 15 minutes.

2 Press the E button to select another lullaby from the list. (Fig. 3)

3 To adjust the sound level of the lullaby, press the volume + or the volume – button on the

baby unit (Fig. 4).

Note: You can only set the loudspeaker volume on the baby unit when a lullaby is playing. If you set

the volume for the lullaby higher, the sound will also be louder when you use the talk function on the

parent unit.

4 To stop lullaby playing, press the K button on the baby unit.

ENGLISH 7
