16
JetStream Gigabit Smart Switch
Chapter 4 Connection
4.1 Ethernet Port
Connect an Ethernet port of the switch to the computer by RJ45 cable as the following
figure shown.
RJ45 Port
RJ45 Cable
Figure 4-1 Connecting the RJ45 Port
4.2 SFP Port
Connect the SFP port to a SFP module as shown below.
SFP Port
SFP Module
Figure 4-2 Inserting the SFP Module
4.3 Verify Installation
After completing the installation, please verify the following items:
■
There are 5~10cm of clearance around the sides of the device for ventilation and
the air flow is adequate.
■
The voltage of the power supply meets the requirement of the input voltage of the device.
■
The power socket, device and rack are well grounded.
■
The device is correctly connected to other network devices.
