JetStream Gigabit Smart Switch

4.4 Power On

Plug in the negative connector of the provided power cord into the power socket of the

device, and the positive connector into a power outlet as the following figure shown.

Figure 4-3 Connecting to Power Supply

Note: The gure is to illustrate the application and principle. The power plug you get

from the package and the socket in your situation will comply with the regulation in

your country, so they may differ from the gure above.

4.5 Initialization

After the device is powered on, it begins the Power-On Self-Test. A series of tests run

automatically to ensure the device functions properly. During this time, its LED indica-

tors will respond as follows:

■

The PWR LED indicator will light on all the time.

■

After keeping off for several seconds, the LED indicators of all the ports will flash

momentarily and then turn off again after the initialization.

■

The SYS LED indicator will flash, which represents a successful initialization.
