JetStream Gigabit Smart Switch

Installation

Rack

Figure 2-3 Rack Installation

Caution:

■

Please set 5~10cm gaps around the device for air circulation.

■

Please avoid any heavy thing placed on the device.

■

Please mount devices in sequence from the bottom to top of the rack and ensure a

certain clearance between devices for the purpose of heat dissipation.
