Aten CS1782A [9/54] Introduction
![Aten CS1784A [9/54] Introduction](/views2/1211079/page9/bg9.png)
1
Chapter 1
Introduction
Overview
The CS1782A / CS1784A USB DVI Dual Link KVMP
TM
Switch charts a
revolutionary new direction in KVM (Keyboard, Video, Mouse) switch
functionality by combining a 2/4 port KVM switch with a 2 port USB hub at
the same time as providing an interface for a Digital Visual Interface (DVI)
monitor. In addition, the CS1782
A / CS1784A comes with ATEN’s new Video
DynaSync
TM
technology, which eliminates boot-up display problems and
optimizes resolution, and power on detection, which means if one computer is
powered off, the CS1782
A / CS1784A will automatically switch to the next
powered-on computer. Further innovations include the latest in mouse port-
switching – simply double-click on the scroll wheel of a USB mouse to change
ports – and gaming keyboard support, making the CS1782
A / CS1784A the new
standard for desktop KVM switches.
As a KVM switch, the CS1782
A / CS1784A allows users to access two or four
computers from a single USB keyboard, USB mouse, and monitor console. As
a USB 2.0 hub, it permits each computer to access any peripherals connected
to the hub on a one-computer-at-a-time basis.
The unit’s independent switching feature, allows the KVM focus to be on one
computer while the USB peripheral focus is on another. This eliminate the need
to purchase a separate USB hub as well as the need to purchase separate stand-
alone peripheral sharers.
The CS1782
A / CS1784A further improves on previous designs with DVI
connectors, and the transfer of keyboard and mouse data to the computers via
a fast, reliable USB connection. DVI supports both digital video input (flat
panel displays, data projectors, plasma displays, digital TVs and set-top boxes)
and analog video input (traditional monitors and TVs). The CS1782
A /
CS1784
A also breaks into the computer gaming environment as it supports
gaming keyboard functions. It allows users to enjoy and control their game
applications with familiar keyboard inputs without having to change to a
compatible keyboard.
The CS1782
A / CS1784A is audio enabled, with the CS1782A supporting 7.1
channel surround sound audio and the CS1784
A supporting 2.1 channel
surround sound audio. You can listen to the audio output of each computer on
