Chapter 4. Hotkey Operation

Keyboard Operating Platform

The CS82U / CS84U’s default port configuration is for a PC compatible

keyboard operating platform. If your console uses a PC compatible keyboard

and you have a Mac attached to a port, for example, you can change the port’s

keyboard operating platform configuration so that the PC compatible keyboard

emulates the Mac keyboard. The procedure is as follows:

1. Bring the KVM focus to the port you want to set.

2. Invoke HSM (see page 17)

3. Press and release the appropriate Function key (see table below). After

completing this procedure, you automatically exit HSM.

List Switch Settings

To see a listing of the current switch settings, do the following:

1. Open a text editor or word processor and place the cursor in the page

window.

2. Invoke HSM (see page 17).

3. Press and release [F4] to display the settings.

USB Reset

If the USB loses focus and needs to be reset, do the following:

1. Invoke HSM (see page 17).

2. Press and release [F5].

Function Key Operation

[F2]

Enables Mac keyboard emulation, see Mac Keyboard,

page 23 for details.

[F3] Enables Sun keyboard emulation, see Sun Keyboard,

page 24 details.

[F10] Automatically detects and sets the keyboard operating

platform.
