CE774 / CE775 User Manual

Requirements

Consoles

 Two (2) VGA monitors capable of the highest resolution that you will be

using on any computer in the installation

Note: If you connect a DDC type monitor to the Local Unit, the monitor

that connects to the Remote Unit must be able to support the highest

video resolution that the DDC monitor can provide

 A USB keyboard

Note: You can use different brands and models of USB keyboard on the

Local and Remote Units, but support for multi-function keyboards

is limited to the standard 104 keys.

 A USB mouse

Note: You can use different brands and models of mouse on the Local and

Remote Units, but only the left and right mouse buttons and scroll

wheel features are supported. Other mouse features are not

supported.

 Stereo microphone and stereo speakers (optional)

Computers

The following equipment must be installed on each computer that is to be

connected to the system:

 Two (2) VGA ports

 USB host controller and Type A USB port

Cables

 For optimal signal integrity, and to simplify the layout, we strongly

recommend that you use the high quality custom USB KVM Cable that is

provided with this package.

 Cat 5e/6 cable is the minimum required to connect the Local and Remote

CE774 / CE775 Units. Cable of a lower standard will result in degrading

of the video signal. For best performance, we strongly recommend an

ATEN 2L-2801 cable.

 VGA cable
