VS1912 User Manual
2
Features
Supports DisplayPort – an advanced video interface for the clear video
display
Lockable connectors for the DisplayPort ports
Single system for Digital Signage / Video Wall displays
Video Wall feature provides profiles that you can customize into various
layouts using a web GUI
Supports Asymmetric Video Wall applications
Small form factor: 1U
Flexible scheduling for different profiles
Widgets available: Video / Images / Flash / Webpage / Text / Banner /
Clock / RSS / RTSP Streaming / Video Capture in
Multiple Control Methods – system management via RS-232 (serial
control) and Ethernet (Web GUI) connections
HDMI Capture input
Built-in USB 3.0 & USB 2.0 ports for Web-Camera applications and
profile uploads
Built-in bi-directional RS-232 serial port for high-end system control
Superior video quality – from 640 x 480 to HDTV resolutions of 480p,
720p, 1080i and 1080p (1920 x 1080)
ESD protection for DisplayPort ports
Firmware Upgradeable
Rack Mountable
