Aten VC812 [21/33] System

3. Operation

System

In the OSD Menu screen, navigate to 4. System and press the Menu pushbutton

to open the System submenu, as follows:

View the current input resolution and firmware version, as well as reset the

VC812 to its factory default settings.

 Input Res. Info: This shows the current input resolution used by the

device.

 F/W Version: This shows the current firmware version.

 Factory Reset: Select this if you want to reset the device back to the

factory default settings.

Exit

In the OSD Menu screen, navigate to 5. Exit and press the Menu pushbutton to

close the OSD.
