Aten VC812 [32/33] Specifications

VC812 User Manual

Specifications

VC812

Video Input

Interface 1 x HDMI Type A Female (Black)

Impedance 100 Ώ

Video Output

Interface 1 x HDB-15 Female (Black)

Impedance 75 Ώ

Video

Max. Pixel Clock 165 MHz

Max. Resolution Up to 1920 x 1200

Scaler Resolutions 480p; 480i; 576p; 576i; 800x600;

1024x768; 1280x720; 1280x1024;

1360x768; 1440x900; 1400x1050; 1600x1200;

1680x1050; 1080i; 1080p; 1920x1200

Audio

Output Analog: 1 x Mini Stereo Jack Female (Black)

Digital: 1 x RCA (Yellow)

Power

Connectors 1 x DC Jack

Consumption 5 VDC, 10W

Environmental

Operating Temperature 0 - 40°C

Storage Temperature -20°C - 60°C

Humidity 20 – 90% RH, Non-condensing

Physical Properties

Housing Metal

Weight 0.29 kg (0.64 lb)

Dimensions (L x W x H) 11.00 x 8.30 x 2.80 cm (4.33 x 3.27 x 1.1 in.)

Carton Lot 5 pcs
