- 11 -

Specifications

Model VS-0202 VS-0204

PC - Monitor Connection 2 - 2 2 - 4

Connectors Out 2 x HDB-15 (f)

2 x 3.5mm Mini Stereo (f)

4 x HDB-15 (f)

4 x 3.5mm Mini Stereo (f)

In 2 x HDB-15 (m)

2 x 3.5mm Mini Stereo (f)

2 x HDB-15 (m)

2 x 3.5mm Mini Stereo (f)

Power DC Jack

LEDs Power 1 (blue)

Source 1 1 (green)

Source 2 1 (orange)

In 1 2 (green) 4 (green)

In 2 2 (orange) 4 (orange)

Toggle Switches 2 4

VGA Resolution 1920x1440@60Hz

VGA DDC2B Support Port 1 Ports 1 and 3

Slide Switch 1 N/A

Signal Type VGA / SVGA / XGA

Sync Range Sync Positive/Negative

Power Supply DC 5.3V, 2.4A

Power Consumption DC 5.3V 8W DC 5.3V 9W

Cable Distance 65 meters maximum (Video Matrix Switch to monitor)

Environment Operating

Temperature

0°~50°C

Storage

Temperature

-20°~60°C

Humidity 0~80% RH, Non-condensing

Physical

Properties

Enclosure Metal

Weight 0.47 kg 0.69 kg

Dimensions

(LxWxH)

13 x 7.7 x 4.5 cm 20 x 7.7 x 4.5 cm
