VGA Pin Assignments

Getting Help

If you need to contact ATEN technical support with a problem,

visit our website at www.aten.com.

Pin Signal Pin Signal Pin Signal

1 Red Video 6 Analog Ground 11 ID0

2 Green Video 7 Analog Ground 12 ID1

3 Blue Video 8 Analog Ground 13 Horizontal Sync

4 ID2 9 NC 14 Vertical Sync

5 Ground 10 Ground 15 ID3

Limited Warranty

IN NO EVENT SHALL THE DIRECT VENDOR'S LIABILITY EXCEED

THE PRICE PAID FOR THE PRODUCT FROM DIRECT, INDIRECT,

SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES RESULTING

FROM THE USE OF THE PRODUCT, DISK, OR ITS DOCUMENTATION.

The direct vendor makes no warranty or representation, expressed, implied, or

statutory with respect to the contents or use of this documentation, and especially

disclaims its quality, performance, merchantability, or fitness for any particular

purpose.

The direct vendor also reserves the right to revise or update the device or

documentation without obligation to notify any individual or entity of such

revisions, or update. For further inquiries, please contact your direct vendor.
