33
Using BIOS
Serial Port O Configuration
Use this item to show the information of Serial Part O Configuration
configuratio configuration.
Parallet Part O Configuration
Parallel Port [Enabled]
Device Settings IO=378h; IRQ=5;
Change Settings [Auto]
Device Mode [Standard and B1-dire...]
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Version 2.10.1208. Copyright (C) 2010, American Megatrends, Inc.
+/- :Change Opt.
Enter : Select
F1:General Help
:Select Screen
:Select Item
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
Enable or Disable Parellel
Port (LPT/LPTE)
Main Advanced Chipset M.I.B III Boot Security Save & Exit
Parallel Port Configuration
Use this item to show the information of Super IO configuration.
Serial Port (Enabled)
Use this item to enable or disable the serial COM port.
Device Settings (IO=3F8h;IRQ=4)
Use this item to setting devices parameter.
Change Settings (Auto)
Use this item to change the settings automatically.
Serial Part O Configuration
Serial Port [Enabled]
Device Settings IO=3F8h; IRQ=4;
Change Settings [Auto]
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Version 2.10.1208. Copyright (C) 2010, American Megatrends, Inc.
+/- :Change Opt.
Enter : Select
F1:General Help
:Select Screen
:Select Item
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
Enable or Disable Serial
Main Advanced Chipset M.I.B III Boot Security Save & Exit
Press <Esc> to return to the Super IO configuration menu page.
