Introducing the Motherboard

Chapter 1

Introducing the Motherboard

Introduction

Thank you for choosing the HDC-M motherboard of high performance, enhanced

function. This motherboard has an onboard FT1 CPU (AMD dual core E-350 APU/

AMD single core E-240 APU/AMD dual core C-50 APU/AMD single core C-30

APU)* with a Mini-ITX form factor of 225 x 170 mm.

The motherboard is equipped with advanced full set of I/O ports in the rear panel,

including one DVI port (optional HDMI port), one VGA port, six USB 2.0 ports, one

LAN port, and audio jacks for microphone, line-in and line-out.

*The onboard CPU is optional, please take the actual motherboard as

the standard.

Note: The eJIFFY function is optional, basing on the different CPU using

on the motherboard, please take the actual product for the standard.

The motherboard incorporates the AMD Hudson D1 FCH chipset. The HDC-M

supports two PCI slots which full compliant with PCI rev 2.2 specification at 33

MHz.One PCIE16X slot run at x4 bandwidth which full compliant with to the PCI

Express Base Spec-fication revision 2.0.This motherboard supports up to 8 GB of

system memory with single channel DDR3 1333(OC)/1066MHz. It implements an

EHCI compliant interface that provides twelve USB 2.0 ports (six USB 2.0 ports and

three USB 2.0 headers support additional six USB ports).
