Introducing the Motherboard
• AMD Hudson D1 FCH
• Onboard AMD FT1 CPU(AMD dual core E-350 APU/AMD
single core E-240 APU/AMD dual core C-50 APU/AMD single
core C-30 APU)*
• Single-channel DDR3 memory architecture
• 2 x 240-pin DDR3 DIMM sockets support up to 8 GB
• Supports 1333(OC)/1066 DDR3 SDRAM
• Supported by AMD Hudson D1 FCH
• 4x Serial ATA 3.0 Gb/s devices
• Realtek ALC662 supports 6-channel HD audio Codec.
• Realtek RTL8105E 10/100 LAN (Colay RTL8111-VL Giga
LAN)
• 1 x DVI port (optional HDMI port)
• 1 x VGA port • 1 x PS/2 keyboard&Mouse
• 6 x USB 2.0 ports
• 1 x RJ45 LAN connector
• 1 x Audio port (Line in, microphone in, line out)
Chipset
Memory
Expansion
Slots
Storage
Audio
LAN
Rear Panel I/O
CPU
Specifications
• 2 x PCI slot
• One PCIE 16x slot(x4 mode)
*The onboard CPU is optional, please take the actual motherboard as the
standard.
•1 x LPT header
•1 x Clear CMOS header
•1 x Front panel header
•1 x TPM header
•1 x SPDIFO header
Form Factor
• mATX 225mm x 170mm
• AMI BIOS with 16Mb SPI Flash ROM
• Supports ACPI & DMI
• Supports Plug and Play, STR(S3)/STD(S4), Hardware monitor,
• Audio, LAN, can be disabled in BIOS
• Supports Dual Display (optional)
System BIOS
Internal I/O
Connectors &
Headers
• 1 x 3-pin SYS_FAN connector
• 1 x 4-pin CPU_FAN connector
• 1 x 24-pin ATX Power Supply connector
• 1 x Speaker header
• 1 x Front panel audio header
• 4 x SATA 3Gb/s connectors
• 1 x SPI_DEBUG header
• 3 x USB 2.0 headers
• 1 x COM header
• 1 x CASE open header
