Using BIOS
CPU Smart FAN Control (Enabled)
This item allows you to enable or disable the control of the CPU fan speed by
changing the fan voltage.
Scroll to this item and press <Enter> to view the following screen:
Smart Fan Function
PC Health Status
On motherboards support hardware monitoring, this item lets you monitor the
parameters for critical voltages, temperatures and fan speeds.
Main Advanced Chipset M.I.B III Boot Security Save & Exit
+/- : Change Opt.
Enter/Dbl Click : Select
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
CPU Tct1 : +66
System temperature : +30 C
CPU FAN : N/A
SYS FAN : N/A
CPU Vcore : +1.320 V
VDIMM : +1.560 V
-=- PECI Mode -=-
Offset to TCC Activation Temp. : -59
Smart Fan Function
PC Health Status
Main Advanced Chipset M.I.B III Boot Security Save & Exit
+/- : Change Opt.
Enter/Dbl Click : Select
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
Enable CPU SmartFan
CPU Smart Fan Control Enabled
Smart Fan Mode Normal
High Limit Temperature 60
Low Limit Temperature 37
High Limit PWM 200
Low Limit PWM 56
SYS Smart Fan Control [Enabled]
Smart Fan Mode [Normal]
High Limit Temperature 60
Low Limit Temperature 37
High Limit PWM 200
Low Limit PWM 56
