Using BIOS

This page enables you to set the clock speed and system bus for your system. The

clock speed and system bus are determined by the kind of processor you have

installed in your system.

M.I.B III Menu

Memory Clock (Auto)

This item is used to set the memory clock.

Memory Mode (Auto)

This item is used to set the memory mode.

CAS# Latency (tCL) (8 CLK)

This item determines the operation of DDR SDRAM memory CAS (column address

strobe). It is recommanded that you leave this item at the default values. The 2T

setting requires faster memory that specifically supports this mode.

Row Precharge Time (tRP) (8 CLK)

This item specifies Row precharge to Active or Auto-Refresh of the same bank.

RAS# to CAS# Delay (tRCD) (8 CLK)

This item specifies the RAS# to CAS# delay to Rd/Wr command to the same bank.

RAS# Active Time (tRAS) (20 CLK)

This item specifies the RAS# active time.

Main Advanced Chipset M.I.B III Boot Security Save & Exit

+/- : Change Opt.

Enter/Dbl Click : Select





: Select Screen

/Click: Select Item

F1: General Help

F2: Previous Values

F3: Optimized Defaults

F4: Save & Exit

ESC/Right Click: Exit

This Option Allows User to

select different Memory

Clock. Default value is

400Mhz.

Memory Clock Auto

Memory Mode Auto

CAS# Latency (tCL) 8 CLK

RAS# to CAS# Delay (tRCD) 8 CLK

Row Precharge Time (tRP) 8 CLK

RAS# Active Time (tRAS) 20 CLK
