ECS Elitegroup H97I-DRONE [11/86] H97i drone user manual
![ECS Elitegroup H97I-DRONE [11/86] H97i drone user manual](/views2/1212415/page11/bgb.png)
5
H97I-DRONE
USER MANUAL
Chapter 1
Table of Motherboard Components
LABEL COMPONENTS
1. CPU Socket
LGA1150 socket for 4
th
and 5
th
Generation Intel
®
Core
TM
processors
2. BT Battery
3. ATX_POWER Standard 24-pin ATX power connector
4. DIMM1~2 240-pin DDR3 Module slots
5. LDC Debug Card header
6. M.2 M.2 slot for Wifi/ Bluetooth Card
7. PCIEX16 PCI Express Gen3 x16 slots for graphics interface
8. F_AUDIO Front panel audio header
9. ATX12V 8-pin +12V power connector
10. ME_UNLOCK ME unlock header-for factory use only
11. CPU_FAN 4-pin CPU cooling fan connector
12. SYS_FAN 4-pin system cooling fan connector
13. SPI_DEBUG Debug diagnosis header for factory use only
14. SATA3_1~5 Serial ATA 6Gb/s connectors
15. BZ Buzzer
16. F_PANEL Front panel switch/ LED header
17. F_USB Front panel USB 2.0 header
18. CASE CASE open header
19. CLR_CMOS Clear CMOS jumper
20. USB3F Front panel USB3.0 header
