Chapter 3
H97I-DRONE USER MANUAL
44
Intel ME BIOS Extension Configuration
Use this item to show the information of Intel ME BIOS Extension Configuration.
TCC Activation Temperature (DTS) 100
Main Advanced Chipset M.I.B. X Security Boot Exit
Enable/Disable Intel (R) Ac-
tive Management Technology
BIOS Extension.
Note: iMAT H/W is always
enabled. This option just con-
trols the BIOS extension.
If enabled, this requires addi-
tional fireware in the SPI
device
+/- : Change Opt.
Enter/Dbl Click : Select
lk
mn
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
Intel AMT Disabled
BIOS Hotkey Pressed Disabled
MEBx Selection Screen Disabled
Intel AMT (Disabled)
Use this item to control the BIOS extension execution. If enabled, this requires ad-
ditional firmware in the SPI device.
BIOS Hotkey Pressed (Disabled)
This item allows you to enable or disable the BIOS Hotkey Pressed.
Press <Esc> to return to the Advanced Menu page.
MEBx Selection Screen (Disabled)
This item allows you to enable or disable the MEBx Selection Screen.
