ECS Elitegroup H87H3-M4 [9/94] H87h3 m4 user manual
![ECS Elitegroup H87H3-M4 [9/94] H87h3 m4 user manual](/views2/1212425/page9/bg9.png)
5
H87H3-M4
USER MANUAL
Chapter 1
Table of Motherboard Components
LABEL COMPONENTS
1. CPU Socket
LGA1150 socket for Intel
®
4
th
Generation Core
TM
Famil
y
p
rocessors
2. PWR_FAN 3-pin Power cooling fan connector
3. CPU_FAN 4-pin CPU cooling fan connector
4. DDR3_1~4 240-pin DDR3 Module slots
5. ATX_POWER Standard 24-pin ATX power connector
6. USB3F Front panel USB 3.0 header
7. ME_UNLOCK ME unlock header-for factory use only
8. SATA3_1/2 & SATA3~6 Serial ATA 6Gb/s connectors
9. CIR Consumer Infrared header
10. CASE CASE open header
11. F_PANEL Front panel switch/LED header
12. F_USB1~2 Front panel USB 2.0 headers (Gray header supports EZ Charger)
13. TPM Trusted platform module header
14. CLR_CMOS Clear CMOS jumper
15. LPT Parallel port header
16. SPK Speaker header
17. SPDIFO SPDIF out header
18. F_AUDIO Front panel audio header
19. COM Onboard serial port header
20. PCIE1~3 PCI Express x1 slots
21. PCIEX16 PCI Express Gen2 x16 slot for graphics interface
22. SYS_FAN 3-pin system cooling fan connector
23. ATX12V1 4-pin +12V power connector
